MARINE PLYWOOD BWP GRADE IS : 710

Sablo BWP 710 Plywood is a high perfor- mance product. Every piece of Sablo BWP 710 Plywood is made with high grade, ‘Treat- ed and Tenderized’ wood veneers from ma- tured plantation timbers of Eucalyptus and Poplar.

Sablo Marine Plywood is bonded with fortified Phenol Formaldehyde Synthetic Resin as per standards of IS: 848:1974 under controlled temperature and pressure with adequate timings to obtain unmatched bonding. All the veneers, which go to the manufacturing of Sablo Marine Plywood is treated with An- ti-Termite & Anti-Fungus chemicals.

Hence offering maximum protection, ensur- ing every inch of Sablo plywood is protected from ‘Termite and Borer’.

Applications:

  • Boats
  • Lake Platform
  • Boat Dock
  • Deck
  • Bathroom Walls
  • Kitchen Walls and Sub-flooring

TECHNICAL SPECIFICATION (IS:710)
PROPERTY REQUIREMENT RESULT
Moisture Content 5-15% 7.2%
Glue Shear Strength in dry condition Individual Min. 1078.7 Newton
Average Min. 1323.9 Newton		 1450 Newton

1700 Newton
Glue Shear Strength in wet condition Individual Min.
784.5 Newton
Average Min.

980.7 Newton

 1250 Newton

1420 Newton
Glue Shear Strength in mycological test Individual Min. 784.5 Newton
Average Min. 980.7 Newton		 1120 Newton

1300 Newton
Tensile Strength
a.  Parallel to grain direction
b.  Right angle to grain direction
c.  Sum of both directions		 Min 420 Kgf./cm2
Min 250 Kgf./cm2
Min 845 Kgf./cm2		 645 Kgf./cm2
395 Kgf./cm2
1040 Kgf./cm2

Standard Thickness : 6mm, 19mm, 12mm 16mm and 19mm

Standard Sizes:

  • 2440mm x 1220mm
  • 2440mm x 920mm
  • 2140mm x 1220mm
  • 2140mm x 920mm
  • 1840mm x 1220mm
  • 1840mm x 920mm

GENERAL PURPOSE PLYWOOD IS : 303

Sablo Plywood is available in Moisture Resistant (MR) and Boiling Water Resistant (BWR) grades are used for interior like ship cabins, railway coaches, bus and truck bodies, kitchen cabinets etc and exterior wood working applications.

MR and BWR Grade ply bonded with special resin as per standards of IS 848:1974 under controlled temperature and pressure with requisite timing to obtain unmatched bonding. It’s available in alternate wood and hardwood core.

Applications:

  • Ceilings
  • Floor
  • Beds
  • Door Panel Insert
  • Kitchen Furniture
  • Partitions
  • Vehicle Seats and Backs
  • Wall paneling
  • Furniture Like: Chair,Table etc.
TECHNICAL SPECIFICATION (IS:303)
TEST DETAILS REQUIREMENT RESULT
DIMENSIONS
Length
Width
Thickness		 2440mm (+6mm)
1220mm (+3mm)
18mm (+5%)		 2441mm
1221mm
18.5mm
Edge Straightness (%) 0.2% Maximum 0.02
Squareness (%) 0.2% Maximum 0.11
Average Moisture Content 15% Maximum 8%
Visual Appearance Free from visual Defects Free from Visual Defects

Standard Sizes:

  • 2440mm x 1220mm
  • 2440mm x 920mm
  • 2140mm x 1220mm
  • 2140mm x 920mm
  • 1840mm x 1220mm
  • 1840mm x 920mm

Standard Thickness: 6mm, 9mm, 12mm 16mm and 19mm
